U-shaped bike rack for outdoor bicycle parking
A fixable U-shaped bicycle rack built from 40 mm tube in Q235 steel or SUS304 stainless steel. It is made for schools, offices, parks and public bike parking, and bolts down to the ground.
The overall dimensions are 300 x 150 x 200 mm and each rack weighs about 15 kg.
Key features
- U-shaped design from 40 mm tube
- Q235 steel or SUS304 stainless steel
- Hot-dip galvanizing, powder coating or electropolish
- Fixable to the ground
Specifications
- Overall dimensions: 300 x 150 x 200 mm
- Tube diameter: 40 mm
- Weight: 15 kg
- Material: Q235 steel or SUS304
- Finish: hot-dip galvanizing, electrostatic powder coating or electropolish
- Minimum order: 10 pieces
- Lead time: 10-15 days
- Price range: US$8-15
Materials and finishes
- Q235 carbon steel: a widely used low-carbon structural steel that welds and forms easily. It needs a protective coating or galvanizing outdoors.
- SUS304 stainless steel: an austenitic stainless steel with good corrosion resistance, a clean look and low maintenance.
- Hot-dip galvanizing: the part is dipped in molten zinc, which forms a thick, long-lasting rust barrier.
- Powder coating: dry powder applied electrostatically and cured into a hard, even layer. It comes in many colours and resists chipping and fading.
Where it is used
- Schools and universities
- Offices and residential buildings
- Parks and public bike parking
- Shops and transport stops
How customization works
- Send your drawing, sample photo or size list.
- We confirm the design, material and finish with you.
- Production starts, with quality inspection before shipment.
Frequently asked questions
Can the rack be fixed to the ground?
Yes, the rack is a fixable design. Tell us your surface so we can confirm the fixing details.
What are the minimum order and lead time?
The minimum order is 10 pieces and the lead time is 10-15 days.
Which material should I choose?
Hot-dip galvanized or powder-coated Q235 is the economical choice. SUS304 resists corrosion better.
